For projects across Bendigo, AS 4678 and the local geotechnical guidelines set the standard for ground improvement. The region's expansive clay profiles — derived from the Ordovician bedrock weathering — demand chemical stabilization to control shrink-swell behavior. We design lime and cement stabilization treatments that target plasticity reduction and strength gain, adapting the binder content to the subgrade conditions encountered in the Loddon Valley. Before specifying the mix, we always run a classification of soils to confirm the clay mineralogy and a CBR vial to establish the baseline bearing capacity. The methodology follows the Austroads pavement design framework, with field trials required for acceptance.
Bendigo's Plasticity Indices above 35% require pH-verified lime dosages and mandatory field UCS to confirm the design strength before pavement placement.
Methodology and scope
Bendigo's soils typically show Liquid Limits above 65% in the upper 2 metres, with Plasticity Indices exceeding 35%. That level of reactivity demands more than a standard 3% lime addition. We apply the Eades and Grim pH test to determine the lime modification optimum, then adjust with cement for the target unconfined compressive strength — usually 1.0 to 1.5 MPa at 7 days for pavement subbase applications. A permeability field test helps verify the treated layer's hydraulic behaviour before the final compaction pass. For deep treatment below 600 mm, we incorporate deep soil mixing techniques to reach the problematic clay without full excavation. The process includes:
pH monitoring every 50 m of treated lane
moisture-density control per AS 1289.5.4.1
7-day and 28-day UCS specimens from the field
Technical reference image — Bendigo
Local considerations
Bendigo sits on one of Australia's most reactive clay sequences, with the Black Range and Harcourt granites contributing to variable parent material. The 2021 census recorded over 100,000 residents, and the urban expansion into the Huntly and Epsom corridors has exposed new subdivisions to high-plasticity subgrades. Without lime and cement stabilization, pavement life on these sites drops by half. We have seen untreated sections develop differential heave exceeding 40 mm within two wet-dry cycles — enough to crack a reinforced slab. Stabilization is not optional here; it is the difference between a road that lasts 25 years and one that fails in five.
Short-term treatment to reduce plasticity and improve workability. Applied to the A-horizon clay common in central Bendigo, with field verification using the Eades and Grim pH method. Typical dosage 3–5% hydrated lime.
02
Cement Stabilization for Pavement Subbase
Cement addition (3–6% by mass) to achieve structural UCS values for road and industrial slab subbase. Includes 7-day and 28-day compressive strength testing from field-moulded cylinders per AS 1012.9.
03
Lime-Cement Combined Treatment
Dual binder approach for soils with PI > 40% where lime alone cannot deliver the required strength. Two-stage mixing with intermediate curing. Common in the Strathfieldsaye and Maiden Gully developments.
Applicable standards
AS 4678:2002 — Earth-retaining structures (binder-treated fills), AS 1289.5.4.1 — Compaction control (moisture-density relationship), Austroads AGPT04A — Guide to Pavement Technology Part 4A, AS 1289 — Standard test method for using pH to estimate the soil-lime proportion
Frequently asked questions
What is the difference between lime modification and cement stabilization?
Lime modification targets plasticity reduction and workability improvement; it changes the clay's physical behaviour without creating a strong cemented matrix. Cement stabilization adds structural strength (UCS) and is used where the treated layer must carry traffic loads. Many Bendigo projects use both: lime first to tame the clay, then cement to lock the strength.
How much does lime and cement stabilization cost in Bendigo?
The cost ranges between AU$1,180 and AU$3,850 per 100 m² depending on treatment depth, binder content, and access. A typical 250 mm pavement subbase treatment with 5% lime + 3% cement runs approximately AU$2,100 per 100 m² including laboratory mix design and field testing. Volume discounts apply for subdivisions exceeding 5,000 m².
How long does the curing period take before paving?
For lime-only modification, compaction is immediate and paving can follow within 24 hours. For cement stabilization, a minimum 7-day curing period is required before the asphalt or concrete wearing course. In Bendigo's cooler months (May–August), we extend the cure to 10 days to account for slower hydration.
Do I need a geotechnical investigation before specifying stabilization?
Yes. Without Atterberg limits, particle size distribution, and natural moisture content data, the binder dosage is guesswork. We recommend a minimum of one test pit per 1,000 m² to sample the full treatment depth. The classification results directly inform the lime and cement percentages in the mix design.
